Intel Core i3 Processor Raptor Lake CPU - 14th Gen Intel Core i3-14100 Processor, 4 Total Cores, 8 Total Threads, 4.7GHZ Max Turbo Frequency, 12MB Intel Smart Cache, 60W Processor Base Power, 110W Maximum Turbo Power, Intel UHD Graphics 730, 1.5GHz Max Dynamic Frequency, 4096 x 2160 @ 60Hz  Max HDMI Resolution, FCLGA1700 Sockets Supported, Retail Box, 1 Year Warranty.

Product Overview

The Intel Core i3-14100 is a 14th Gen Raptor Lake desktop processor with 4 performance cores, 8 threads, and a max turbo of 4.7 GHz at a 60W TDP (110W max turbo). It features 12 MB Smart Cache, Intel UHD Graphics 730 for up to 4 displays (8K support), DDR5-4800/DDR4-3200 up to 192 GB, and PCIe 5.0 with 20 lanes on LGA 1700 socket.

Specifications

•Product Code: BX8071514100-CA
•Description: Intel Core i3 14th Gen Processor
•Total Cores: 4
•Performance-cores: 4
•Efficient-cores: 0
•Total Threads: 8
•Max Turbo Frequency: 4.7 GHz
•Performance-core Max Turbo Frequency: 4.7 GHz
•Performance-core Base Frequency: 3.5 GHz
•Cache: 12 MB Intel® Smart Cache
•Total L2 Cache: 5 MB
•Processor Base Power: 60 W
•Maximum Turbo Power: 110 W
•Marketing Status: Launched
•Launch Date: Q1 2024
•Embedded Options Available: Yes
•Use Conditions: PC/Client/Tablet
Memory Specifications
•Max Memory Size: 192 GB
•Memory Types: Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s
•Max Memory Channels: 2
•Max Memory Bandwidth: 76.8 GB/s
GPU Specifications
•GPU Name: Intel® UHD Graphics 730
•Graphics Max Dynamic Frequency: 1.5 GHz
•Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
•Execution Units: 24
•Max Resolution (HDMI): 4096 × 2160 @ 60Hz
•Max Resolution (DP): 7680 × 4320 @ 60Hz
•Max Resolution (eDP – Integrated Flat Panel): 5120 × 3200 @ 120Hz
•DirectX Support: 12
•OpenGL Support: 4.5
•OpenCL Support: 3.0
•Multi-Format Codec Engines: 1
•Intel® Quick Sync Video: Yes
•Intel® Clear Video HD Technology: Yes
•Displays Supported: 4
•Device ID: 0x4692
Expansion Options
•Direct Media Interface (DMI) Revision: 4.0
•Max DMI Lanes: 8
•Scalability: 1S Only
•PCI Express Revision: 5.0 and 4.0
•PCI Express Configurations: Up to 1x16+4, 2x8+4
•Max PCI Express Lanes: 20
Package Specifications
•Sockets Supported: FCLGA1700
•Max CPU Configuration: 1
•Thermal Solution Specification: PCG 2020C
•TJUNCTION: 100°C
•Package Size: 45 × 37.5 mm
•Max Operating Temperature: 100°C
